Shantui Bulldozer DH10-B2

ENGINE POWER: With 86kW/2200rpm, this engine conforms to China-III/EU Stage IIIA emission regulation.
OVERALL WEIGHT: 9680kg/10140kg
ENGINE MODEL: QSF3.8Applicable
Sale: 0
$0.00
/ Pieces
|
1 Pieces(Min. Order)
Quantity
-
+
(0 In Stock)
Description
Description

Shantui bulldozer DH10-C2



ENGINE POWER: With 86kW/2200rpm, this engine conforms to China-III/EU Stage IIIA emission regulation.

OVERALL WEIGHT: 9680kg/10140kg

ENGINE MODEL: QSF3.8Applicable







DH10-C2 is A 100 horsepower Stage hydrostatic drive bulldozer developed for the Chinese and Southeast Asian markets, which meets the requirements of China Ⅲ/EU Stage Log A emission regulations.  DH10-C2 hydraulic bulldozer, reliable performance, moderate price, comfortable operation, high flexibility.



Power System

• The installed Cummins electronic control engine conforms to China-III/EU StageⅢA emission regulation and features stronger power and higher energy-saving and environmental friendliness. The fuel system with three-stage filter guarantees good adaptability to low-quality diesel in Southeast Asian markets.

• Shantui’s hydrostatic drive optimization technology is applied to achieve maximum working efficiency and most reasonable fuel economy:



Control system

• The double-module (Function and safety) controller architecture verifies with each other to achieve higher safety and reliability.

• The malfunction self-diagnosis function is provided to accurately indicate the malfunction cause and shorten the downtime.

• The service software with distinct access hierarchy features high simpleness and practicability and easy learning and understanding.

● It can be configured with TRIMBLE, TOPCON, LEICA, MOBA and other GPS automatic leveling systems to meet users' precise leveling working conditions and improve efficiency.

PARAMETER

Parameter name

DH10-C2 XL (Extended version)

DH10-C2 LGP(Super-wetland version)

Performance parameters





Operating weight (Kg)

9680kg/21341lb (With traction frame)

10140kg/22355lb (With traction frame)

Ground pressure (kPa)

44.4

34

Engine





Engine model

QSF3.8

QSF3.8

Rated power/rated speed (kW/rpm)

86/2200

86/2200

Overall dimensions





Overall dimensions of machine (mm)

4442*2860*2885

4442*3200*2885

Driving performance





Forward speed (km/h)

0~9km/h(5.6mph)

0~9km/h(5.6mph)

Reversing speed (km/h)

0~9km/h(5.6mph)

0~9km/h(5.6mph)

Chassis System





Center distance of track (mm)

1650

1790

Width of track shoes (mm)

460

630

Ground lengthmm

2320

2320

Tank capacity





Fuel tank (L)

197

197

Working device





Blade type

PAT

PAT

Digging depth (mm)

450

450

Ripper type

Three-tooth ripper

Three-tooth ripper

Ripping depth (mm)

340

340
