Shantui SD22 Pedal (L.H.) and (R.H.)154-43-41130 154-43-41140
Part Name:Pedal (L.H.) and (R.H.)
Part Number: 154-43-41130 154-43-41140
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | MODEL | |
| 1 | 154-43-41130 | Pedal (L.H.) | 1 | ||
| 2 | 154-43-41140 | Pedal (R.H.) | 1 | ||
| 3 | 07021-01090 | Oil cup | 2 | ||
| 4 | GB290-HK3520 | Bearing | 4 | ||
| 5 | 06122-03504 | Dust ring | 4 | ||
| 6 | 04010-01032 | Woodruff key | 2 | ||
| 7 | 154-43-41150 | Rocker | 2 | ||
| 8 | 01010-51245 | Bolt | 2 | ||
| 9 | 01602-21236 | Washer | 2 | ||
| 10 | 23Y-26B-01000 | Bracket | 1 | ||
| 11 | 154-54-42430 | Washer | 1 | ||
| 14 | 09311-41237 | Buffer bolt | 2 | ||
| 15 | 01580-11210 | Nut | 2 | ||
| 16 | 154-43-41260 | Spring | 2 | ||
| 17 | 04210-21456 | Crossings board | 2 | ||
| 18 | 04205-11438 | Pin | 2 | ||
| 19 | 04050-14022 | Cotter pin | 2 | ||
| 20 | 23Y-26B-05000 | Lever | 2 | ||
| 21 | 01582-11411 | Nut | 2 | ||
| 22 | 01508-41408 | Nut | 2 | ||
| 23 | 01010-51230 | Bolt | 9 | ||
| 24 | 01643-31232 | Washer | 9 | ||
