Shantui Parts SD22 Fuel tank 23Y-04B-01000 17S-04H-01000
Part Name:Fuel tank
Part Number: 23Y-04B-01000 17S-04H-01000
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | |
| SD22,SD22E, | SD22R | |||
| SD22S,SD22D | ||||
| 1 | 23Y-04B-01000 | Fuel tank | 1 | |
| 1 | 17S-04H-01000 | Fuel tank | 1 | |
| 2 | 07056-18416 | Filter screen | 1 | 1 |
| 3 | 23Y-04B-00001 | Oil dipstick | 1 | 1 |
| 4 | 16Y-04C-02000 | Fuel tank cap | 1 | 1 |
| 5 | 07002-12434 | O-ring | 1 | 1 |
| 6 | 23Y-04-00006 | Connector | 1 | 1 |
| 8 | 07700-40460 | Valve gate | 3 | 3 |
| 9 | 23Y-04-00004 | Elbow | 1 | 1 |
| 9 | 07042-20108 | Plug | 1 | 1 |
| 10 | 23Y-04-00003 | Connector | 1 | 1 |
| 11 | 23Y-04-00002 | Nipple | 1 | 1 |
| 12 | 07270-01265 | Hose | 1 | 1 |
| 13 | 07280-01210 | Hose clip | 1 | 1 |
| 14 | 23Y-04-40000 | Support | 1 | 1 |
| 15 | 01010-52045 | Bolt | 6 | 6 |
| 16 | 01010-51230 | Bolt | 6 | 6 |
| 17 | 01010-52050 | Bolt | 4 | 4 |
| 18 | 01602-22060 | Washer | 4 | 4 |
| 19 | 01643-32060 | Washer | 10 | 10 |
| 20 | 07000-15150 | O-ring | 1 | 1 |
| 21 | 23Y-04-00005 | Flange | 1 | 1 |
| 22 | 01643-31232 | Washer | 6 | 6 |
