Shantui Parts SD22 lubrication valve ass’y 154-15-34000
Part Name:lubrication valve ass’y
Part Number: 154-15-34000
Machine Model:SD22
| INDEXNO. | PART NO. | DESCRIPTION | Q’TY |
| (154-13-31000) | torqueflow transmission ass’y | 1 | |
| 204-1 | 154-15-21111 | case | 1 |
| 2 | 09608-05080 | plate, name | 1 |
| 3 | 04418-03060 | rivet | 4 |
| 4 | 04530-02438 | bolt, eye | 2 |
| 5 | 154-15-21121 | gasket | 1 |
| 6 | 04020-01228 | pin, dowel | 1 |
| 7 | 01010-51240 | bolt | 15 |
| 8 | 01602-21236 | washer | 15 |
| (154-15-34000) | lubrication valve ass’y | 1 | |
| 9 | 154-15-24110 | body | 1 |
| 10 | 175-15-14130 | valve | 1 |
| 11 | 175-15-14120 | spring | 1 |
| 12 | 175-15-14141 | guide | 1 |
| 13 | 07000-63032 | o-ring | 2 |
| 14 | 175-15-14150 | cover | 2 |
| 15 | 01010-50825 | bolt | 4 |
| 16 | 01602-20825 | washer | 4 |
| 17 | 154-15-34170 | sleeve | 1 |
| 18 | 07000-62018 | o-ring | 1 |
| 19 | 175-15-44180 | sleeve | 1 |
| 20 | 07000-62018 | o-ring | 2 |
| 21 | 175-15-14161 | gasket | 1 |
| 22 | 01010-51065 | bolt | 4 |
| 23 | 01602-21030 | washer | 4 |
