Shantui Parts SD22 Tilt Cylinder Assy 23Y-63B-01000 Body 23Y-63B-01100
Part Name: Tilt Cylinder Assy
Part Number: 23Y-63B-01000
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY |
| 1 | 23Y-63B-01100 | Cylinder body | 1 |
| 2 | 154-63-52760 | Bush | 1 |
| 3 | 23Y-63B-01200 | Piston rod | 1 |
| 4 | 23Y-63B-01004 | Dust ring | 1 |
| 5 | 07000-13062 | O-ring | 1 |
| 6 | 23Y-63B-01002 | Cylinder head | 1 |
| 7 | 23Y-63B-01005 | KY-ring | 1 |
| 8 | 23Y-63B-01300 | Step seal | 1 |
| 9 | 23Y-63B-01003 | Guide ring | 1 |
| 10 | 07146-05192 | Guard circle | 1 |
| 11 | 07000-15190 | O-ring | 1 |
| 12 | 23Y-63B-01001 | Piston | 1 |
| 13 | 23Y-63B-01400 | Glyd ring | 1 |
| 14 | 23Y-63B-01006 | Support ring | 2 |
| 15 | 07165-16264 | Nut | 1 |
| 16 | 154-63-52184 | Hose | 1 |
| 17 | 154-63-52284 | Hose | 1 |
| 18 | 07000-13030 | O-ring | 2 |
| 19 | 01010-50860 | Bolt | 4 |
| 20 | 01010-50845 | Bolt | 4 |
| 21 | 01643-30823 | Washer | 8 |
| 22 | 195-63-52871 | Clip | 1 |
| 23 | 01010-51225 | Bolt | 1 |
| 24 | 01643-31232 | Washer | 1 |
| 25 | 154-63-52684 | Cover | 1 |
| 26 | 01010-51435 | Bolt | 3 |
| 27 | 01643-31645 | Washer | 3 |
| 28 | 154-63-52370 | Washer | 1 |
| 29 | 01643-32060 | Washer | 12 |
| 30 | 01010-52090 | Bolt | 12 |
| 31 | 154-63-52890 | Plug | 2 |
