Shantui SD22 Radiator assembly 158-03-A0000 23Y-03B-0000
Part Name: Radiator assembly
Part Number: 158-03-A0000 23Y-03B-0000
Machine Model: SD22
| NO. | PART NO. | PART NAME | Q'TY | ||
| SD22, | SD22D | SD22R, | |||
| SD22E | SD22S | ||||
| 0 | 158-03-A0000 | Radiator and piping | 1 | ||
| 0 | 23Y-03B-00000 | Radiator assembly | 1 | ||
| 0 | 22M-03-00000 | Radiator assembly | 1 | ||
| 1 | 22M-03-80700 | Top tank | 1 | ||
| 1 | 154-03-11117 | Top tank | 1 | 1 | |
| 2 | 07056-00048 | Filter screen | 1 | 1 | 1 |
| 3 | 07057-03271 | Snap ring | 1 | 1 | 1 |
| 4 | 07053-10000 | Filler cap | 1 | 1 | 1 |
| 5 | 07053-00002 | Gasket | 1 | 1 | 1 |
| 6 | 154-03-11682 | Pressure valve | 1 | 1 | |
| 6 | 22M-03-81000 | Pressure valve | 1 | ||
| 7 | 22M-03-80800 | Filter screen | 1 | ||
| 7 | 175-03-32570 | Filter screen | 1 | 1 | |
| 8 | 07000-13045 | O-ring | 1 | 1 | 1 |
| 11 | 07040-13618 | Plug | 1 | 1 | 1 |
| 12 | 07002-43634 | O-ring | 1 | 1 | 1 |
| 13 | 154-03-11565 | Tube ass'y | 1 | 1 | 1 |
| 14 | 07000-12070 | O-ring | 1 | 1 | 1 |
| 15 | 01010-51240 | Bolt | 4 | 4 | 4 |
| 17 | 07042-20108 | Plug | 1 | 1 | 1 |
| 18 | 07281-00809 | Hose clip | 2 | 2 | 2 |
| 19 | 154-03-11574 | Hose | 1 | 1 | 1 |
| 20 | 01011-51640 | Bolt | 4 | 4 | 4 |
| 21 | 154-03-13240 | Gasket | 4 | 4 | 4 |
| 22 | 22M-03-80500 | Mold core | 1 | ||
| 22 | 154-03-21132 | Mold core | 1 | 1 | |
| 23 | 154-03-11143 | Gasket | 2 | 2 | |
| 23 | 22M-03-80004 | Gasket | 2 | ||
| 24 | 22M-03-80005 | Bolster | 4 | ||
| 24 | 154-03-11151 | Bolster | 4 | 4 | |
| 25 | 154-03-21123 | Tank | 1 | 1 | |
| 25 | 22M-03-80200 | Tank | 1 | ||
| 27 | 01602-21030 | Washer | 94 | 94 | 94 |
| 28 | 195-03-22530 | Support | 2 | 2 | |
| 28 | 22M-03-80410 | Support | 2 | ||
| 29 | 22M-03-80110 | Absorber | 4 | ||
| 29 | 195-03-22520 | Absorber | 4 | 4 | |
| 31 | 154-03-13160 | Top bracket | 2 | 2 | 2 |
| 32 | 01091-52220 | Bolt | 4 | 4 | 4 |
| 33 | 154-03-13170 | Bottom bracket | 2 | 2 | 2 |
| 36 | 01010-51075 | Bolt | 6 | 6 | 6 |
| 37 | 01010-51230 | Bolt | 15 | 15 | 15 |
| 39 | 198-03-21530 | Plate | 2 | 2 | |
| 39 | 22M-03-80003 | Plate | 2 | ||
