Shantui SD13 Fuel Tank Cap 07050-21200
Part Name: Fuel Tank Cap
Part Number: 07050-21200
Machine Model: SD13
Hotline:0086-18052293627 (whatsapp & wechat)
|
|
FUEL TANK AND PIPING |
|
| No. |
Part No. |
Description |
Q’ty |
| 1 |
10Y-04B-01000 |
fuel tank |
1 |
| 2 |
07050-21200 |
cap |
1 |
| 3 |
10Y-04-00003 |
gauge |
1 |
| 4 |
07056-18416 |
strainer |
1 |
| 5 |
01643-31445 |
washer |
6 |
| 6 |
01010-31430 |
bolt |
3 |
| 7 |
01010-31465 |
bolt |
3 |
| 8 |
07000-02135 |
O-ring |
1 |
| 9 |
16Y-04-00006 |
cover |
1 |
| 10 |
01643-51032 |
washer |
6 |
| 11 |
01010-31025 |
bolt |
6 |
| 12 |
16Y-04-00007 |
joint |
2 |
| 13 |
07700-40460 |
valve |
2 |
| 14 |
16Y-04-00008 |
joint |
1 |
| 15 |
07280-01210 |
clamp |
1 |
| 16 |
07270-01265 |
tube |
1 |
| 17 |
16Y-04-00003 |
joint |
1 |
| 18 |
07102-20330 |
tube |
1 |
| 19 |
16Y-04-00002 |
joint |
1 |
| 20 |
07102-20232 |
tube |
1 |
| 21 |
01010-51220 |
bolt |
3 |
| 22 |
01643-51232 |
washer |
3 |
| 23 |
16Y-04-10000 |
clip |
3 |
| ※24 |
10Y-04B-00001 |
bolt |
1 |
| ※25 |
10Y-04-00005 |
washer |
4 |
| 26 |
16Y-04-40000 |
tube |
1 |
| ※27 |
10Y-04B-00002 |
bolt |
1 |
| 28 |
10Y-04B-02000 |
tube |
1 |
