Shantui SD23 Drawbar Assy 154-69-11000
Part Name: Drawbar Assy
Part Number: 154-69-11000
Machine Model: SD23
Hotline:0086-18052293627 (whatsapp & wechat)
|
154-69-11000 |
牵引架总成 drawbar ass’y |
1 |
| 715-1 |
175-69-21212 |
牵引架 drawbar |
1 |
| 2 |
150-74-11350 |
衬套 bushing |
2 |
| 3 |
154-69-11341 |
销合件 pin ass’y |
1 |
| 4 |
01052-51675 |
螺栓 M16×75 bolt |
1 |
| 5 |
01592-11619 |
螺母 M16 nut |
1 |
| 6 |
04050-14030 |
开口销 pin, cotter |
1 |
| 7 |
150-74-11122 |
托架（左） bracket |
1 |
| 8 |
150-74-11112 |
托架（右） bracket |
1 |
| 9 |
150-74-11140 |
螺栓 bolt |
4 |
| 10 |
01580-13326 |
螺母 M33 nut |
4 |
| 11 |
01643-33380 |
垫圈 washer |
4 |
| 12 |
01010-83385 |
螺栓 M33×85 bolt |
6 |
| 13 |
01643-33380 |
垫圈 washer |
6 |
