Shantui Spare Parts SD22 BLADE CONTROL LEVER 23Y-86B-01000
Part Name: Blade Control Lever
Part Number: 23Y-86B-01000
Machine Model: SD22
| Index No. | Part No. | Description | Q’ty |
| 624-1 | 16Y-86C-11000 | knob | 1 |
| 2 | 195-43-44220 | nut | 1 |
| 3 | 195-61-45140 | boot | 1 |
| 4 | 23Y-86B-00002 | base | 1 |
| 5 | 01220-40508 | nut | 4 |
| 5A | 01601-20513 | washer | 4 |
| 6 | 23Y-86B-02000 | button | 1 |
| 7 | 175-61-31750 | boss | 1 |
| 8 | 01640-22232 | washer | 1 |
| 9 | 195-61-45230 | nut | 1 |
| 10 | 01580-10806 | nut | 1 |
| 11 | 04050-13018 | pin,cotter | 1 |
| 12 | 04211-20844 | yoke | 1 |
| 13 | 04205-10822 | pin, shaft | 1 |
| 14 | 23Y-86B-04000 | lever | 1 |
| 15 | 01580-10806 | nut | 1 |
| 16 | 01643-30823 | washer | 1 |
| 22 | 23Y-86B-01000 | lever | 1 |
| 23 | 06120-02016 | bearing,,needle | 1 |
| 24 | 06122-02004 | seal, bearing | 1 |
| 25 | 154-61-16471 | shaft | 1 |
| 26 | 07020-00000 | fitting,grease | 1 |
| 27 | 01010-50820 | bolt | 1 |
| 28 | 01602-20825 | washer | 1 |
| 29 | 154-61-16411 | yoke | 1 |
| 30 | 01010-50835 | bolt | 1 |
