Shantui Spare Parts SD22 Filler Cap 07051-00000
Part Name:Filler cap
Part Number: 07051-00000
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY |
| 0 | 23Y-60B-00000 | Oil tank valve ass'y | 1 |
| 1 | 23Y-60B-01000 | Fuel tank | 1 |
| 2 | 141-60-33730 | Filter screen | 1 |
| 3 | 07051-00000 | Filler cap | 1 |
| 4 | 154-60-52112-01 | Plate | 1 |
| 5 | 07715-11257 | Ring | 1 |
| 6 | 07715-00651 | Cover | 1 |
| 7 | 07115-21074 | Cover | 1 |
| 8 | 01598-11011 | Nut | 4 |
| 9 | 07044-12412 | Plug | 1 |
| 10 | 07002-12434 | O-ring | 1 |
| 11 | 141-60-33181 | Pad | 1 |
| 12 | 01010-51025 | Bolt | 41 |
| 13 | 01602-21030 | Washer | 41 |
| 14 | 23Y-60B-02000 | Rocker | 1 |
| 15 | 23Y-60B-03000 | Rocker | 1 |
| 16 | 23Y-60B-04000 | Rocker | 1 |
| 17 | 01010-50830 | Bolt | 6 |
| 18 | 01602-20825 | Washer | 6 |
| 19 | 06120-02520 | Bearing | 6 |
| 20 | 154-60-51450 | Shaft | 3 |
| 21 | 154-60-12370 | Oil seal | 3 |
| 22 | 01640-22440 | Washer | 6 |
| 23 | 04010-00519 | Woodruff key | 6 |
| 24 | 141-60-33270 | Lever | 3 |
| 27 | 141-60-32170 | Yoke | 6 |
| 28 | 01641-21016 | Washer | 2 |
| 29 | 04205-01028 | Pin | 6 |
| 30 | 04050-03015 | Cotter pin | 6 |
| 31 | 154-60-51401 | Oil ilter ass'y | 1 |
| 32 | 07000-13050 | O-ring | 1 |
| 33 | 01140-51430 | Stud | 2 |
| 34 | 01582-11411 | Nut | 2 |
| 35 | 01602-21442 | Washer | 4 |
| 36 | 07000-12065 | O-ring | 1 |
| 37 | 01010-51430 | Bolt | 2 |
