Shantui Spare Parts SD22 Servo Valve 702-12-13001
Part Name:Servo valve
Part Number: 702-12-13001
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | MODEL |
| 0 | 702-12-13001 | Servo valve | 1 | |
| 1 | 702-12-13110 | Valve body | 1 | |
| 2 | 07043-70108 | Plug | 2 | |
| 3 | 702-12-12140 | Pin | 1 | |
| 4 | 702-12-12150 | Pin | 2 | |
| 5 | 702-12-12160 | Sleeve | 1 | |
| 6 | 702-12-12390 | Oil seal | 1 | |
| 7 | 04065-04018 | Retaining ring | 1 | |
| 8 | 702-12-12410 | Oil seal | 1 | |
| 9 | 04065-06020 | Retaining ring | 1 | |
| 10 | 702-12-12170 | Rotor | 1 | |
| 11 | 702-12-12180 | Pin | 1 | |
| 12 | 04025-00316 | Cylindrical pin | 1 | |
| 13 | 04000-10520 | Flat key | 3 | |
| 14 | 702-12-12191 | Piston | 1 | |
| 15 | 702-12-12210 | Lever | 1 | |
| 16 | 702-12-12221 | Locking plate | 1 | |
| 17 | 702-12-12230 | Pin | 1 | |
| 18 | 702-12-12240 | Snap ring | 1 | |
| 19 | 702-12-12251 | Spring | 1 | |
| 20 | 04000-10515 | Flat key | 1 | |
| 21 | 702-12-12420 | Washer | 1 | |
| 22 | 01010-50816 | Bolt | 1 | |
| 23 | 01602-20825 | Washer | 19 | |
| 24 | 702-12-12361 | Bush | 2 | |
| 25 | 702-12-12280 | Washer | 1 | |
| 26 | 702-12-12270 | Washer | 1 | |
| 27 | 01580-11008 | Nut | 1 | |
| 28 | 01602-21030 | Washer | 1 | |
| 29 | 01641-21016 | Washer | 4 | |
| 30 | 702-12-12291 | Lever | 2 | |
| 31 | 702-12-12310 | Bearing | 2 | |
| 32 | 702-12-12320 | Roller | 2 | |
| 33 | 702-12-12331 | Spring | 1 | |
| 34 | 702-12-13120 | Cover | 1 | |
| 35 | 702-12-12340 | Pin | 1 | |
| 36 | 702-12-13140 | Pad | 1 | |
| 37 | 01010-50845 | Bolt | 6 | |
| 38 | 01010-50835 | Bolt | 2 | |
| 39 | 01010-50825 | Bolt | 10 | |
| 40 | 702-12-13160 | Cover | 1 |
