Shantui Spare Parts SD22 Servo Valve Ass’y 702-12-14000
Part Name:servo valve ass’y
Part Number: 702-12-14000
Machine Model:SD22
| Index No. | Part No. | Description | Q’ty |
| 621-1、5、 10、14 | 702-12-14000 | servo valve ass’y,for blade tilt and ripper control | 2 |
| 2 | 07043-00108 | plug | 2 |
| 3 | 702-12-12140 | pin | 1 |
| 4 | 702-12-12150 | pin | 1 |
| 6 | 702-12-12390 | sesl,oil | 1 |
| 7 | 04065-04018 | ring，snap | 1 |
| 8 | 702-12-12410 | sesl,oil | 1 |
| 9 | 04065-06020 | ring，snap | 1 |
| 11 | 702-12-12180 | pin | 1 |
| 12 | 04025-00316 | pin,spring | 1 |
| 13 | 04000-00520 | key | 1 |
| 15 | 702-12-12210 | lever | 1 |
| 16 | 702-12-12451 | detent | 1 |
| 17 | 702-12-12230 | pin | 1 |
| 18 | 702-12-12240 | ring，snap | 1 |
| 19 | 702-12-12251 | spring | 1 |
| 20 | 04000-00515 | key | 1 |
| 21 | 702-12-12420 | washer | 1 |
| 22 | 01010-50816 | bolt | 1 |
| 23 | 01602-20825 | washer,spring | 1 |
| 24 | 04000-00520 | key | 2 |
| 25 | 702-12-12280 | washer | 1 |
| 26 | 702-12-12270 | washer | 1 |
| 27 | 01580-11008 | nut | 1 |
| 28 | 01602-21030 | washer,spring | 1 |
| 29 | 702-12-13220 | cover | 1 |
