Shantui SD22 Coupling ass'y 154-13-41660 154-13-41870
Part Name:Coupling ass'y
Part Number: 154-13-41660 154-13-41870
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | MODEL | |
| 1 | 154-13-41123 | Pump pulley | 1 | ||
| 2 | 154-13-41141 | Gear | 1 | ||
| 3 | 154-13-41160 | Bearing | 1 | ||
| 4 | 154-13-41180 | Bolster | 1 | ||
| 6 | 154-13-41150 | Plate | 6 | ||
| 7 | 01010-81035 | Bolt | 42 | ||
| 8 | 01602-21030 | Washer | 30 | ||
| 9 | 01643-31032 | Washer | 42 | ||
| 10 | 07040-11007 | Plug | 2 | ||
| 11 | 234-13-11211 | Case | 1 | ||
| 12 | 175-13-21220 | Gear | 1 | ||
| 14 | 01643-31232 | Washer | 24 | ||
| 15 | 154-13-11240 | Bearing | 1 | ||
| 16 | 234-13-11250 | Guider | 1 | ||
| 17 | 01010-81230 | Bolt | 32 | ||
| 18 | 195-13-11261 | Plate | 4 | ||
| 19.3 | 154-13-11540 | Turbine pressure plate | 1 | ||
| 19.4 | 154-13-11550 | Rivet | 16 | ||
| 19.1 | 154-13-31520 | Turbine | 1 | ||
| 19 | 154-13-41510 | Turbine ass'y | 1 | ||
| 19.2 | 154-13-41530 | Turbine hub | 1 | ||
| 23.2 | 175-13-21672 | Cover | 1 | ||
| 23.3 | 154-13-41430 | Cover | 1 | ||
| 23 | 154-13-41660 | Coupling ass'y | 1 | ||
| 23.1 | 154-13-41870 | Shaft coupling | 1 | ||
| 26 | 154-13-41651 | Turbine shaft | 1 | ||
| 27 | 154-13-13360 | Bearing | 1 | ||
| 28 | 154-13-11730 | Washer | 1 | ||
| 29 | 04064-06020 | Retaining ring | 1 | ||
| 30 | 175-13-21720 | Sealing ring | 1 | ||
| 31 | 175-13-21691 | Plate | 1 | ||
| 32 | 175-13-21711 | Lock pad | 1 | ||
| 33 | 175-13-21810 | Screw | 2 | ||
| 34 | 154-13-42110 | Guide pulley | 1 | ||
| 35 | 154-13-42120 | Seat ring | 1 | ||
| 36 | 01010-81030 | Bolt | 12 | ||
| 38 | 154-13-52520 | Shaft | 1 | ||
| 39 | 04064-08025 | Retaining ring | 1 | ||
| 40 | 154-13-42710 | Sealing ring | 1 | ||
| 41 | 07000-75190 | O-ring | 1 | ||
| 42 | 154-13-42720 | Cover | 1 | ||
