Shantui Spare Parts SD22 Planet carrier 154-15-32320
Part Name:Planet carrier
Part Number: 154-15-32320
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY |
| 1 | 154-15-32110 | Shaft | 1 |
| 2 | 154-15-32320 | Planet carrier | 1 |
| 3 | 154-15-32470 | Gear | 3 |
| 4 | 154-15-39120 | Bearing | 6 |
| 5 | 09233-05125 | Thrust washer | 24 |
| 6 | 154-15-32530 | Shaft | 3 |
| 8 | 154-15-32460 | Gear | 3 |
| 9 | 154-15-32450 | Gear | 6 |
| 10 | 06007-K516138 | Bearing | 6 |
| 11 | 154-15-32510 | Shaft | 3 |
| 12 | 04260-00635 | Steel ball | 6 |
| 13 | 154-15-32120 | Gear | 1 |
| 14 | 155-15-12620 | Gear ring | 1 |
| 15 | 154-15-31170 | Bolster | 1 |
| 17 | 154-15-22760 | Spring | 12 |
| 18 | 175-15-42780 | Spring | 12 |
| 19 | 154-15-32610 | Gear ring | 1 |
| 20 | 175-15-12713 | Friction disk | 7 |
| 21 | 175-15-42721 | Bolster | 5 |
| 22 | 175-15-42880 | Spring | 36 |
| 23 | 155-15-12892 | Piston | 1 |
| 24 | 154-15-22811 | Sealing ring | 1 |
| 25 | 154-15-31180 | Oil cylinder body | 1 |
| 26 | 145-14-11320 | Plug | 4 |
| 27 | 155-15-12811 | Sealing ring | 1 |
| 28 | 155-15-12770 | Pin | 6 |
| 29 | 155-15-11191 | Bolt | 11 |
| 30 | 155-15-11291 | Bolt | 1 |
| 31 | 145-14-11570 | Washer | 12 |
| 32 | 195-15-12141 | Gasket | 1 |
| 33 | 154-15-32310 | Bearing support | 1 |
| 34 | GB276-61924 | Bearing | 1 |
| 35 | 154-15-31210 | Case | 1 |
| 36 | 195-15-11230 | Plug | 1 |
| 37 | 07042-20211 | Plug | 1 |
| 38 | 07018-11805 | Sealing ring | 2 |
| 39 | GB276-6016 | Bearing | 1 |
| 40 | 04077-00125 | Retaining ring | 1 |
| 41 | 195-15-11240 | Gasket | 1 |
| 42 | 07012-50100 | Skeleton oil seal | 1 |
| 43 | 07000-15290 | O-ring | 1 |
