XCMG Bulldozer TY160

HORSEPOWER Gross:131kw 160HP @1850rpm
OPERATING WEIGHT:17100kg
BLADE CAPACITY Straight Tilt Doze: 3.9m3
Weichai diesel engine WD10G178E25
Sale: 0
$0.00
/ Pieces
|
1 Pieces(Min. Order)
Quantity
-
+
(0 In Stock)
Description
Description

XCMG Bulldozer TY160

HORSEPOWER Gross131kw 160HP @1850rpm

OPERATING WEIGHT17100kg

BLADE CAPACITY Straight Tilt Doze: 3.9m3

Weichai diesel engine WD10G178E25



Weichai diesel engine WD10G178E25 provides an output of 131 kW 160HP with excellent productivity.Vertically opened engine side cover

for easy and safer servicing.Left hand joystick controls all tractor motion. Right hand joystick controls all the movements of blade and ripper.High capacity

Straight tilt dozer combined the highest power in its class with outstanding productivity. Farm Dozer XCMG TY160 New Cheap Dozer for Sale Near Me.



Main structural features:

1. By introducing Komatsu D65A-8 bulldozer technology from Japan and absorbing the advantages of D60A-8, our company developed TY160 crawler bulldozer through localization design.

2. Using weichai Steyer WP10G178E355 engine, the crude fuel filter is water filter, the fuel filter is always a rotary fuel filter assembly, and the air filter is an air filter assembly with Tebo type prefilter.   Strong power, reliable performance, convenient after-sales service.

3. Shock-absorbing console and isolation buffer material cab can reduce noise and vibration, so that the operation is more comfortable.



OPERATOR’S COMPARTMENT

All steering, direction, and speed changes are made by three joysticks on the left-hand. If the operator wants to move

the machine the front left, he simply pulls the first left joystick back. If the operator wants to turn the machine to the front right,

he simply pulls the third left joystick back.

For smoother riding comfort, power train components and hydraulic control valves are mounted to the frame with rubber pads to soften vibration and shut out noise. The

walk-through operator compartment is uncluttered for smooth entry and exit. An adjustable seat with backrest is standard equipment.



Electronic monitoring system

An electronic monitoring system prevents minor problems from developing into major ones. All meters and gauges are controlled by a microcomputer, which provides a wide indication range for an easier, more precise reading.



RELIABILITY FEATURES

Powerful WD10G178E25 diesel engines provides a massive output of 131 kW 160 HP. The engine power is transmitted smoothly to the final drives via a high-efficiency torque,

A flat bottom frame, the monocoque track frames and forward-mounted pivot shafts provide good maneuverability in muddy terrain by preventing mud from building up under the frame.

PARAMETER

Name

Remarks

Specifications

Overall size of the machinemm

Straight shovel, traction rod

5128×3416×3120

Straight shovel, three toothed soil loosen

6215×3416×3120

The use quality of the whole machinekg

Straight shovel, traction rod

17100

Straight shovel, three toothed soil loosen

18700

Maximum traction power (kN)

148

Minimum turning radius (mm)

3100

Maximum climbing performance (°)

30

Minimum ground clearance (mm)

No crawler

400

Average ground specific pressure (MPa)

0.065

Forward speed (km/h)

F1

3.1

F2

5.47

F3

9.07

Back speed (km/h)

R1

4.03

R2

7.12

R3

11.81

Tracked ground length (mm)

2430

Caterpillar center distance (mm)

1880

Production efficiency (m3/h)

30m distance

350

Engine

Model

Weichai WD10G178E25

type

Water cooling,straight line,four stroke,direct injection

The number of cylinder - bore * stroke (mm)

6126×130

Rated power (kW)

131

Rated speed (r/min)

1850

Maximum torque (N.m/r/min)

830/10001200

Fuel consumption rate (g/kW.h)

≤210

Walking system

type

Swing type and balance beam suspension structure

Pitch (mm)

203.2

Number of wheels of single side belt

2

Number of single side pulley

unilateral and 2 bilateral

6

Crawler height (mm)

60

Working device

Straight shovel single shovel capacity (M3)

3.9

The maximum lifting height of the blade (mm)
